Outdoor Fixtures
Strike M Strobe
IP65 strobe and wash with motorized tilt
RGB wash panels and 6500 K white strobe tubes, with 185° motorized tilt and an IP65 rating.
- 14 RGB segments and 28 white segments
- DMX-512, RDM and Art-Net control
- 0–100% dimming and strobe up to 20 Hz
Strike M Strobe / TECHNICAL DATA
Technical specifications
Light source
- RGB panel
- 784 × 0.5 W RGB 3-in-1 LEDs
- RGB segments
- 14 segments (2 × 7)
- White strobe tubes
- 392 × 3 W cool-white LEDs
- White colour temperature
- 6500 K
- White segments
- 28 segments (2 × 14)
Movement & effects
- Movement
- 185° motorized tilt
- Dimmer
- 0–100% electronic dimming
- Shutter
- Electronic shutter, up to 20 Hz
- Built-in effects
- Internal LED macro effects
Control & connections
- Protocols
- USITT DMX-512, RDM, Art-Net
- DMX channel modes
- 8 / 11 / 13 / 24 / 30 / 47 / 68 / 74 / 97
- RDM
- Bidirectional communication
- Display
- Illuminated graphic LCD touchscreen
- Signal connections
- Seetronic IP65 XLR 5-pin or 3-pin input/output
- Network connections
- RJ45 input/output for Art-Net
- Power connection
- Seetronic PowerCON TRUE1 input
Electrical & thermal
- Power supply
- 100–240 V AC, 50–60 Hz
- Rated power
- 1400 W
- Cooling
- Temperature-controlled cooling with overheating protection
- Maximum ambient temperature
- 50°C / 122°F
Physical & protection
- IP rating
- IP65
- Dimensions
- 500 × 150 × 340 mm (head horizontal)
- Net weight
- 15.0 kg
- Gross weight
- 17.0 kg
